| Conductor | Insulation | |
| Tinned copper | Silicone compound type 2GI1 to DIN VDE 0207 part 20 | |
| Sheath | Electrical | |
| Inner sheath: glass-fibre braiding Outer sheath: silicone compound type 2GM1 to DIN VDE 0207 part 21 Colour: variable | Test voltage: 20 kV Breakdown voltage: min. 30 kV | |
| Temperature | Flame | |
| Operating temperature range, fixed: up to +180 °C | DIN VDE 0482-332-1-2 / DIN EN 60332-1-2 / IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B) | |
| Approval | ||
| Halogen-free: DIN VDE 0482 part 267 / DIN EN 50267-2-2 / IEC 60754-2 (equivalent DIN VDE 0472 part 813) Low smoke density: yes Wheather-resistant: yes |
FZLSI1X0,50
| Code | FZLSI1X0,50 |
|---|---|
| Cable Type | 1 x 0,5 |
| Ø mm | 5,0 |
| Weight Kg/Km | 36,0 |
