Team Crane Reelmine Antitwisting
Cables designed for power connections to all types of mobile equipment and vehicles used in quarries, open-pit mining and other large-scale civil engineering operations; for applications, construction plants, industry etc.
Thanks to the external PUR sheath it can be used as a festoon cable or simply as a power cable for machinery in tunnels, mining and grinding sites.
For these types of cable we can carry out the cutting to size service and divide the packages according to the customer's needs.
| Name | Cable Type | Ø mm | Weight Kg/Km |
|---|---|---|---|
| MINE3X25+3G6+2X1,5 | 3 x 25 + 3 x 6 + 2 x 1,5 | 27,0 | 1.250,0 |
| MINE3X35+3G6+2X1,5 | 3 x 35 + 3 x 6 + 2 x 1,5 | 29,3 | 1.550,0 |
| MINE3X50+3G10+2X1,5 | 3 x 50 + 3 x 10 + 2 x 1,5 | 33,5 | 2.300,0 |
| MINE3X95+3G16+2X1,5 | 3 x 95 + 3 x 16 + 2 x 1,5 | 42,5 | 3.850,0 |
| MINE3X240+3G50+2X1,5 | 3 x 240 + 3 x 50 + 2 x 1,5 | 63,5 | 8.950,0 |
| MINE3X25+3G6+2X2,5 | 3 x 25 + 3 x 6 + 2 x 2,5 | 27,0 | 1.313,0 |
| MINE3X35+3G6+2X2,5 | 3 x 35 + 3 x 6 + 2 x 2,5 | 29,3 | 1.628,0 |
| MINE3X50+3G10+2X2,5 | 3 x 50 + 3 x 10 + 2 x 2,5 | 33,5 | 2.415,0 |
| MINE3X70+3G16+2X2,5 | 3 x 70 + 3 x 16 + 2 x 2,5 | 38,5 | 3.308,0 |
| MINE3X95+3G16+2X2,5 | 3 x 95 + 3 x 16 + 2 x 2,5 | 42,5 | 4.043,0 |
| MINE3X120+3G25+2X2,5 | 3 x 120 + 3 x 25 + 2 x 2,5 | 48,5 | 5.540,0 |
| MINE3X150+3G25+2X2,5 | 3 x 150 + 3 x 25 + 2 x 2,5 | 54,0 | 6.405,0 |
| MINE3X185+3G35+2X2,5 | 3 x 185 + 3 x 35 + 2 x 2,5 | 58,5 | 7.560,0 |
| MINE3X240+3G50+2X2,5 | 3 x 240 + 3 x 50 + 2 x 2,5 | 63,5 | 9.398,0 |
| MINE3X50+3G10+2X4 | 3 x 50 + 3 x 10 + 2 x 4 | 34,4 | 2.231,0 |
| MINE3X95+3G16+2X4 | 3 x 95 + 3 x 16 + 2 x 4 | 42,9 | 3.815,0 |
| MINE3X150+3G25+2X4 | 3 x 150 + 3 x 25 + 2 x 4 | 51,6 | 5.790,0 |
| MINE3X70+3G16+4X2,5 | 3 x 70 + 3 x 16 + 4 x 2,5 | 38,9 | 3.120,0 |
| MINE3X120+2G25+2X(2X2,5) | 3 x 120 + 2 x 25 + 2 x (2 x 2,5) | 55,1 | 5.490,0 |
| MINE5G150+2X2,5 | 5 x 150 + 2 x 2,5 | 63,4 | 8.425,0 |
| MINE5G150+3X2,5 | 5 x 150 + 3 x 2,5 | 64,1 | 8.480,0 |
| MINE4G150+2X4 | 4 x 150 + 2 x 4 | 57,7 | 6.890,0 |
| MINE5G150+2X4 | 5 x 150 + 2 x 4 | 63,5 | 8.450,0 |
